Deskripsi
| Specifications | Range |
| Voltage LED steps | AC: 24, 48, 120, 208, 240, 277, 480, 600 |
| DC: 6, 12, 24, 36, 48, 110, 220, 400 | |
| ACV frequency range | 50/60Hz |
| LED enable input voltage | >4.5V AC/DC |
| Accuracy | -30% to 0% of the indication |
| Range selection | Automatic |
| Max measuring current | ≤1.2mA (600VAC); ≤1.0mA (400VDC) |
| Display delay | LED indication <0.1s |
| Input Impedance | 1MΩ (approx) |
| Continuity test | Range 0 to 400kΩ, guaranteed on < 50kΩ; |
| Low impedance test | 12-250VAC/DC; impedance <6kΩ; |
| Operation time | 30 seconds on / 10 minutes off duty cycle |
| Power supply | 2 x “AAA” 1.5V alkaline batteries, 50mA max |
| Battery life | Approx. 8 hours of continuous use typical |
| Operating Temperature | -10 to 55° C (14 to 131° F) |
| Storage Temperature | -30 to 60° C (-22 to 140° F) |
| Operating Humidity | 10 to 85% RH (non-condensing) |
| Operating Altitude | 2000m (7000 ft.) maximum |
| Dimensions | 240 x 78 x 40mm (9.4 x 3 x 1.6″) |
| Weight | 260g (9.2oz) |
