Deskripsi
Technical data :
– Speed range I: speed max. (at 50 Hz) : 275rpm
– Speed range II: speed min. (at 50 Hz) : 275rpm
– Speed range II: speed max. (at 50 Hz) : 1300rpm
– Chuck range min. diameter : 3mm
– Speed range I: speed min. (at 50 Hz) : 57rpm
– Torque max. at stirring shaft at 1.000 1/min : 285Ncm
– Torque max. at stirring shaft : 3000Ncm
– Torque max. at stirring shaft at 60 1/min (overload) : 4642Ncm
– Torque max. at stirring shaft at 100 1/min : 3000Ncm
– Chuck range max. diameter : 16mm
– Hollow shaft, inner diameter : 13mm
– Height : 465mm
– Voltage : 3 x 400V
– Frequency : 50Hz
– Power input : 513W
– Depth : 358mm
– Deviation of speed measurement : 10±rpm
– Nominal torque : 30Nm
– Torque I max. : 3000Ncm
– Torque II max. : 620Ncm
– Output max. at stirring shaft : 300W
– Speed min. : 57rpm
– Motor principle : three-phase current
– Speed control : mechanical, stepless
– Width : 145mm
– Permissible ambient temperature min. : 5°C
– Fastening on stand : flange
– Housing material : alu-cast coating / thermoplastic polymer
– Speed display : LED
– Stirring element fastening : chuck
– Permissible ambient temperature max. : 40°C
– Permissible relative humidity : 80%
– Stirring quantity max. per stirring position (H2O) : 200l
– Motor rating input : 513W
– Motor rating output : 370W
– Speed max. : 1300rpm
– Viscosity max. : 100000mPas
– Permissible ON time : 100%
– Setting accuracy speed : 1±rpm
– Weight : 16kg
– Protection class according to DIN EN 60529 : IP 54
