Deskripsi
Specifications :
– Measurement method : Detection of weight loss by heating & drying
– Sample weight : 1 – 80g (as an optional weight sampling)
– Minimum displayable units : Moisture content (solids): 0.1% or 0.01% (selectable), Weight: 0.005g
– Measurable quantities : Moisture content (wet base & dry base), weight, solid content
– Measurement range : 0 – 100% (wet base, solids) / 0 – 500% (dry base)
– Reproducibility (Standard deviation) : 0.1% with samples of 5g or more (When using standard samples and measuring settings as determined by Kett)
– Measurement Mode : Automatic mode, Timed mode (1 – 120 min.)
– Temperature setting range : 30 to 180ºC (in steps of 1ºC)
– Display : Backlit LCD screen (96 x 40mm)
– External output : RS-232C interface
– Communications : Data output from “the data logger software FDL-02” (option)
– Storage of measurement settings : 5 types
– Temperature / humidity operating range : 5 to 40ºC, 85% RH or less (no condensation)
– Heat source : Organic carbon heater (280 W x 2)
– Temperature sensor : Thermistor
– Power supply : AC100 – 120V / 220 – 240V AC (50/60Hz)
– Power consumption : Max. 600 W
– Dimensions and weight : 222 (W) x 360 (D) x 196 (H) mm, 3.2 kg
– Sample dish : Stainless steel (110 mm in diameter, 11 mm in depth)
– Accessories : 2 sample dishes, sample dish handler, wind shield, sample dish tray, spoon, 2 spare fuses, package of aluminium foil sheets (10 per package), power cord, 3P-2P plug adapter, operating manual
– Options: Printer set (includes a VZ-330 printer, a printer interface cable (VZC-14), printer paper, and an AC adapter), printer paper (10 rolls), package of aluminium foil sheets (500 sheets), RS-232C cable, Data Logger software FDL-02, Sample crusher TQ-100, Deodorizing windshield case FW-100
