ELECTRONIC VOLUME CONVERTER ACTARIS CORUS EVO+

Corus Evo+ is an electronic volume converter for commercial and industrial natural gas applications. By measuring temperature and pressure from the gas flow in the meter, Corus Evo+ provides extremely accurate data improving billing precision for utilities and gas distributors. With superior accuracy certifications, simplified maintenance, and evolutivity options, Corus Evo+ is the fundamental component of a reliable gas distribution solution for C&I customers.

Features

High accuracy: compliant with MID according EN12405-1:2018 (0.5%) with optional Class A accuracy (0.3%) according EN12405-2:2012
High modularity (6 optional slots)
ATEX and IEC Ex approved for hazardous area zone 0 or 1
Up to 15 years autonomy
IP 66 Enclosure
Tampering detection features
Encrypted communication with individual keys
Energy index management
Multiple volume interfaces (LF, HF, Cyble, Cyble SC, Encoder)
Operating temperature range: -25°C or -40°C to +70°C
Graphic LCD
Integrated cellular modem

Safeguards Billing Processes

Conceived to safeguard billing processes, Corus Evo+ offers the unique capability to measure gas consumption with a certified 0.3% accuracy*. With embedded anti-tampering, security and encryption features, Corus Evo+ ensures precision and security in the billing process for utilities.

Simplifies Field And Maintenance Operations

Built with proven components, Corus Evo+ features external pressure sensors that facilitate field operations. Enclosed calibration coefficients alleviate on-site maintenance and simplify the replacement of units in the field. With an intuitive Human-Machine Interface crafted through decades of expertise, Actaris Gas’s Corus Evo+ helps streamline field and maintenance efforts.

Evolves With Your Needs

With a distinctive modular design, Corus Evo+ offers flexibility with up to 6 expansion slots. Supporting alarms with on-site reading, Corus Evo+ is programmable to trigger alerts based on user-defined events. Upgradeable remotely, Corus Evo+ adjusts to current and future needs from the field.
